Battery Heating with Temperature Control

Battery Heating Sleeve

Battery heating sleeves available in 70W, 100W, 130W and 160W configurations, with 120V and 240V options for different battery circumferences.

70W to 160W Models
IP65 Protection
120V & 240V Options
Stallion battery heating sleeve
120V and 240V battery heating sleeve
Battery heating sleeve dimensions and technical drawing

Battery Heating Sleeves for Low-Temperature Environments

The Stallion Battery Heating Sleeve is designed to wrap around a compatible battery and provide electrical heating in low-temperature conditions. The range includes four sleeve sizes and power ratings, allowing the appropriate model to be selected according to battery circumference, available voltage and required heating capacity.

The product range is available in 70W, 100W, 130W and 160W configurations. Each size is offered in both 120V and 240V versions. Depending on the selected model, the sleeves are suitable for battery circumferences ranging from approximately 785mm to 1830mm.

Each Battery Heating Sleeve includes built-in temperature control set at approximately 27°C with a tolerance of ±1.5°C, together with high-temperature protection at 32°C. All listed models have an IP65 protection rating, an operating temperature range of -30°C to 55°C and a storage temperature range of -40°C to 80°C. The external power cable is approximately 1.5 metres long and is listed with an American-standard power plug.

Features & Benefits

The Stallion Battery Heating Sleeve range offers multiple power ratings, voltage options and sleeve dimensions for different battery-circumference requirements.

Four Power Ratings

The range includes 70W, 100W, 130W and 160W models for different battery-circumference and sleeve-size requirements.

Built-In Temperature Control

The temperature-control setting is approximately 27°C with a stated tolerance of ±1.5°C.

IP65 Protection

All Battery Heating Sleeve models listed in the catalogue have an IP65 protection rating.

Multiple Sleeve Sizes

Available models cover battery circumferences from approximately 785mm to 1830mm.

Specified Temperature Range

The listed operating-temperature range is -30°C to 55°C, with a storage-temperature range of -40°C to 80°C.

External Power Cable

The external power cable is approximately 1.5 metres long and is listed with an American-standard power plug.

Key Specifications

Technical specifications vary according to the selected sleeve size and voltage configuration.

Request Full Datasheet
ModelsSTAC0071, STAC0072, STAC0101, STAC0102, STAC0131, STAC0132, STAC0161, STAC0162
Rated Voltage120V and 240V configurations
Rated Power70W, 100W, 130W and 160W
Rated Current0.29A to 1.33A
Sleeve Dimensions965 × 192mm to 1880 × 192mm
Battery Circumference785mm to 1830mm
Temperature Control27°C ±1.5°C
High-Temperature Protection32°C
Protection LevelIP65

Battery Heating Configurations

Select the appropriate Battery Heating Sleeve according to battery circumference, available voltage, sleeve dimensions and required power rating.

70W Configurations

Available in 120V and 240V versions for battery circumferences from approximately 785mm to 915mm.

100W Configurations

Available in 120V and 240V versions for battery circumferences from approximately 1090mm to 1220mm.

130W Configurations

Available in 120V and 240V versions for battery circumferences from approximately 1395mm to 1525mm.

160W Configurations

Available in 120V and 240V versions for battery circumferences from approximately 1700mm to 1830mm.

120V Models

Four 120V Battery Heating Sleeve models are available across the complete 70W to 160W power range.

240V Models

Four 240V Battery Heating Sleeve models are available across the complete 70W to 160W power range.

Need Help Selecting
A Battery Heating Sleeve?

Share your battery circumference, available voltage, required power rating and sleeve-size requirements with our team.

Request a Quote
